480 Volt LED 4 Lamp T8 LED T8 Highbay 4XL Highbay Fixture 88 Watt Clear - General Fixtures | Energy Efficient LED by Alamo Lights - Energy Efficient | by Alamo Lights
480 Volt LED 4 Lamp T8 LED T8 Highbay 4XL Highbay Fixture 88 Watt Clear - General Fixtures | Energy Efficient LED by Alamo Lights - Energy Efficient | by Alamo Lights
Couldn't load pickup availability
High-Performance Commercial LED Light Fixture | Made in the USA
Key Features:
- Commercial Grade Durability: Built to meet rigorous safety, quality, and performance standards.
- Fast & Free Shipping: In-stock and ready to ship at no extra cost.
Certified Safety & Quality Assurance:
Our fixtures are rigorously tested by trusted third-party organizations, including UL, ETL, or CSA certifications, alongside DLC compliance. This ensures top-tier safety, adherence to U.S. electrical codes, and unmatched quality. Rebates available—contact us for details.
Included LED Lamps:
- Flicker-Free & Shatterproof: Designed with clear polycarbonate for durability and optimal performance.
- Energy Efficient: Producing an impressive 180 lumens per watt (imported).
- Certified: ETL Sanitation & DLC Listed for reliability and safety.
Technical Specifications:
- Material: Constructed with 20-gauge cold-rolled steel, a baked white enamel finish, and a mirrored aluminum reflector.
- Pre-Wired for Convenience: Comes with lamp holders, a luminaire disconnect, and four daisy-chaining connection points.
- Input Voltage: 110V-277V standard (480V option available).
- Power: 72W usage, producing 12,960 lumens at 180+ LPW.
- Color Temperature: 5000K daylight (custom temperatures available).
- Lifespan: Rated for over 50,000 hours (L70).
- Beam Angle: 120° coverage.
- Operating Range: -20°F to 112°F.
- Size & Weight: 48.0" L x 14.0" W x 3.5" D, 11.25 lbs.
Installation Options:
- Surface Mount: Features pre-drilled holes for straightforward installation (hardware not included).
- Hanging Mount: Compatible with aircraft cable, jack chain, or "S" hooks (mounting kits sold separately).
Advanced Design:
- Built-In LED Drivers: Eliminates the need for ballasts or external drivers.
- Low Maintenance: Engineered for long-term, hassle-free use.
Energy-Efficient Performance:
- Cost Savings: Uses up to 40% less energy compared to T8 fluorescent fixtures.
- Output Equivalent: Fluorescent equivalent of 25,920 lumens.
Damp Location Rated:
Suitable for indoor spaces and covered outdoor areas (not for direct water exposure).
Additional Options & Notes:
- Not Dimmable: Explore our dimmable models for adjustable brightness.
- Accessories: Plug and cord add-ons available.
Warranty:
Enjoy a 5-year warranty covering the entire fixture and included LED lamps.
Product Details:
- Part Number: AL-4SRHBLD88FM480v
Why Choose This Fixture?
Designed and assembled in the USA, this durable, high-efficiency light fixture offers exceptional reliability for commercial applications. Whether you need superior illumination in a warehouse, workshop, or retail space, this fixture is the ultimate lighting solution.
Optimize your lighting setup with a fixture that prioritizes durability, energy savings, and performance.
